29
the set delay time.
During pressure discharge phase code dC is displayed.
10.1.2 Phase codes for normal mode and alarm mode
In normal or alarm mode, the phase code corresponding to the program phase is displayed.
Phase code Description
dC
Pressure discharge waiting time
(disCharge)
Loc
Interlocking switch is closed
(Locked)
OFF
The channel is closed
AGr
Lubricant reservoir low level alarm
(Alarm, Grease)
ALP
Pressure low alarm
(line pressure does not rise high enough during pressurization time)
(Alarm, Low Pressure)
Pulse amount alarm in a ProFlex system
(Alarm Low amount of Pulses)
AHP
Pressure high alarm
(line pressure is not low enough when pressurization phase starts)
(Alarm, High, Pressure)
AIn
Alarm from doser operation indicator (SKF Doser monitor).
The code is displayed only if SKF Doser monitors are in use.
(Alarm, Indicator)
Air
Alarm from the air pressure switch of the grease spray system.
The code is displayed only if air pressure switch is in use.
(Alarm, Air)
APC
Warning message for pump change when doubled pumping center (Dualset) is in
use.
(Alarm, Pump Changed)
