Page 14
EN
Assembly instructions
The gear pump unit must be installed on a
level surface. The base plate must not be under
stress. Sufficient space must be provided dur-
ing installation for later servicing and mainte-
nance work.
4.1.1 Assembly of the gear pump unit
Warning!
When drilling the assembly holes, you
must be careful of any supply lines or
other units, as well as of other hazards
such as moving components.
Maintain safety clearances and comply
with local regulations for assembly and
accident prevention.
There are no restrictions with regard to the
mounting position of all the units.
When UC units are to be mounted lower
than the maximum liquid level, additional
sealing of the flange face is required
(refer to version key).
Warning!
The torque of the fastening screws de-
pends on the customer’s installation.
Make sure that torque is adequate
when installing the base plate!
