Assembly instructions
The gear pump units consist of motor, coupling,
flange and gear pump.
Series 1:
Rated motor output 0.18 kW.
Delivery volume between 0.06 l/min at 60 bar
and 3 l/min at 25 bar.
Flange size:
116 x 116 mm (vertical position) and
80 x 120 mm (horizontal position).
Note!
There is the series 1 still in more customised
implementation with an engine rated power of
0.25 kW. Calculation current is according to
him to lay out type plate.
Series 2:
Rated motor output 0.18; 0.37; 0.55 or
0.75 kW.
By combination with gear pump units of
different sizes (1.2 cm
3
/revolution to
8 cm
3
/revolution), a wide spectrum with regard
to the selection criteria volumetric flow and
operating pressure is achieved.
Delivery volume from 1 l/min at 200 bar up to
10.8 l/min at 30 bar.
Flange size:
150 x 150 mm (vertical position) and
120 x 150 mm (horizontal position).
Series 3:
Rated motor output from 0.75 kW to 4 kW.
The gear pump unit has a displacement
between 4.5 cm
3
/revolution and
26 cm
3
/revolution.
Delivery volume 3.8 l/min at 200 bar
up to 36 l/min at 45 bar.
Flange size:
205 x 205 mm (vertical position) and
180 x 220 mm (horizontal position).
4.2.5 Design
