Skyjack SJ85AJ User Manual

208932AEA SJ85AJ
28
Section 3 – Familiarization Features and Devices
3.4-1 Driving Speed
The driving speed depends upon the machine
conguration (lowered travel position/elevated travel
position). When the MEWP is in the elevated travel
position, the maximum achievable drive speed should
be signicantly less than Lowered Travel Position
drive speed. Refer to Section 7.4.
3.4-2 Driving Direction
The driving function operates in accordance with the
general orientation of the turret’s counterweight over
the chassis (i.e. joystick forward means counterweight
is facing forward). Therefore, the MEWP will move in
the general direction of the joystick’s movement.
3.4-3 Tilt Switch
The tilt switch is located within the base control
console. When the MEWP is on a slope greater than
a predetermined limit, an audible alarm sounds, a
visual indicator illuminates, and boom movement or
drive functions are disabled (refer to Section 3.4-4:
Function Restrictions when Tilted).
WARNING
When tilt settings are exceeded, causing the alarm
to sound and the light to illuminate, the platform
should be lowered and retracted immediately.
Refer to Section 3.7 for instructions on how to
recover from an inclined position.
NOTE
Resetting power to the controls (e.g. e-stop
depressed then pulled out) when the MEWP
is tilted and at the limits of the lowered travel
position will cause the MEWP to be considered
tilted while elevated.
3.4-4 Function Restrictions when Tilted
Mode/Condition Restrictions
In lowered travel position,
tilted, moving into elevated
travel position
Boom extend, boom up, riser
up disabled (on platform and
base, powered by emergency
pump)
Elevated travel position, tilted Drive disabled
1254AA
3.4-5 Platform Load Sensing System
The platform capacity is determined by boom
position (boom extension and boom angle). Each
boom position zone (High Capacity Zone or Low
Capacity Zone) has a separate capacity. Refer to
platform capacity label(s) for maximum platform
capacity of each zone.
The platform load sensing system indicates when the
load is approaching overload status (refer to Section
3.4-6: Overload Status).
If the platform is overloaded while in elevated travel
position, the load sensing system will disable func-
tions as per Section 3.4-6: Overload Status and signal
the operator with an indicator light and an audible
alarm.
If the platform is overloaded while in lowered travel
position, the load sensing system will signal the op-
erator with an indicator light and an audible alarm but
will not disable any functions (refer to Section 3.4-6:
Overload Status).
WARNING
If the platform is overloaded due to contact with an
overhead obstruction, do one of the following:
▪
Remove the obstruction from the platform,
then after a four-second delay normal
functions can be resumed.
▪
Use the emergency power unit to release the
platform from the obstruction.
▪
Do not attempt to free a snagged platform
with lower controls until personnel are
removed from the platform.
NOTE
Movement into the Low Capacity Zone occurs
when the boom is either lowered or extended into
a position where it is raised less than 47 degrees
and extended 3.1 m (refer to Figure 11 and
Figure 12). There are approximately 5 1/2 cutouts
visible on the fly boom when extended 3.1 m.
FAMILIARIZATION
