208932AEA SJ85AJ
76
Section 7 – Technical Diagrams & Specications Tire/Wheel Specifications
7.6 Tire/Wheel Specications
SJ 85AJ
Outrigger R4 18-625
0.48 m x 1.05 m
Type Foam-filled
Tire Ply Rating 16
Wheel Nuts Torque 373 Nm
1250AA-AS
Tire Size
Maximum Wind 12.5 m/s
Maximum Side Force 400 N
Tilt Cutout Setting 5 degrees x 5 degrees
1251AA-AS
Total Capacity (High)
Total Capacity (Low)
Wheel LCP OUP
kg kg kPa kPa
16,805 7,500 1,179 17.0
1252AA-AS
SJ 85AJ
MODEL
Gross Aerial
Platform Weight
Total Aerial Platform Load
The LCP or OUP that an individual surface can withstand varies from structure to structure and is generally determined by
the engineer or architect for that particular structure.
Gross Aerial Platform Weight = Weight + platform capacity
LCP – Locally Concentrated Pressure – is a measure of how hard the aerial platform tire tread presses on the area in direct
contact with the floor. The floor covering (tile, carpet, etc.) must be able to withstand more than the indicated values above.
OUP – Overall Uniform Pressure – is a measure of the average load the aerial platform imparts on the whole surface
projected directly underneath it. The structure of the operating surface (beams, etc.) must be able to withstand more than
the indicated values above.
7.7 Maximum Platform Capacities
7.8 Floor Loading Pressure
