Skyjack SJ85AJ User Manual

SJ85AJ 208932AEA
55
Function Tests Section 4 – Pre-operation
4.3-23 Test Oscillating Axles
WARNING
DO NOT operate any control on platform control
console without proper fall protection secured to
designated location in platform. Failure to avoid
this hazard could result in death or serious injury!
1. Extend y boom 30 cm (12 in.) while on
a rm, level surface.
▪
Result: The steer axles should be locked.
2. Drive one of the steer tires up onto a 15 cm (6
in.) block or curb.
▪
Result: An appropriate tilt of the MEWP
chassis should occur.
3. Retract y boom while in tilt position.
▪
Result: The steer axles should unlock and the
MEWP chassis should level itself to ground.
Oscillating Axle - LockedOscillating Axle - Unlocked
