2. Safety information
3. Receiver Operating Elements
GB 5
Please read this safety information thoroughly before commissioning the device! Prolonged absence: In the event
of prolonged absence or thunderstorms, remove the mains plug of the device from the wall socket. Also disconnect
the antenna connections to avoid storm damage.
SM Electronic GmbH hereby declares that Article No. 19660 complies with the basic requirements and other relevant
regulations of directives 2004/108/EC and 2006/95/EC.
Cleaning: Remove the mains plug before cleaning the device.
Use a dry or damp cloth and make sure that no moisture
penetrates the device!
Objects in the device: Make sure that no objects can enter the
ventilation slots. There is risk of death through electric shock!
Repair: Repairs must be performed by qualified experts. In the event
of improper intervention by a third party, the warranty will be voided
and the safety of the device can no longer be guaranteed! Never
open the housing of the device yourself: Even when disconnected
from the mains, there is an acute risk of death through electric
shock. Internal components can be damaged if touched.
Place of installation: Place the device on a straight and even
surface. To protect the surface from being discoloured as a
result of the natural heat generated by the device, place the
device on a suitable underlay.
Adequate ventilation: The ventilation slots on the device
must never be covered. Ensure that the device has a clearance
of at least 10 cm at the sides and top, and that the heat can be
dissipated upwards unimpeded.
External influences: Never expose the device to moisture
(e.g. condensation or splash water) or direct sunlight. Do not
place the device in the vicinity of heat sources, such as e.g.
heaters or devices that heat up.
Mains voltage: Use the equipment with the voltage specified
on the case only! Do not plug the equipment into the mains
until all connection and installation work has been completed.
Earthing: Antenna systems must always be earthed, paying
heed to the pertinent local and VDE regulations.
ASTRA, EUTELSAT, TÜRKSAT, DiSEqC and Skymaster are registered trademarks.
A
B
1. Mains switch
Switches the device on/off.
2. ON/OFF Lights up green if the device has been
switched on via the ON/Off switch.
3. USB Lights up green if the device is connected.
4. REC Lights up red when recording.
5. Calls the previous channel / leafs through
the menu.
6. Calls the next channel / leafs through the
menu.
7. IR Infrared sensor, receives the signal of the
remote control.
8.
3000 4 digit blue display
1. ANT OUT Connection to analogue SAT
receiver
2. ANT IN Input for an LNB of the satellite
system
3. USB USB-Port, max. 500mA
4. HDMI HDMI port
5.
TV SCART
SCART jack, connection to
aTVset
6. YPbPr Component output for
connecting a Beamer/TV
7. L/R Stereo audio output, for
connection to a stereo system
or TV/VCR (Cinch)
8. SPDIF
Sepate, digital audio output
(coaxial)
9. Mains cable 230V/50Hz
Information on the use of USB devices
If a USB device without its own power supply is
connected, according to the USB specification
the total power consumption must not exceed
500 mA. Otherwise the USB devices may
malfunction or the receiver may be damaged.
USB memories which require more than 500 mA,
for example hard drives with USB Y-cables or hard
drives with a power supply should only be
operated with their own power supply in order
to prevent damage to the receiver or the USB
memory.
Please note that external influences also affect the
USB memory of the receiver. For example, voltage
spikes or voltage reductions may occur due to bad
weather or the USB memory may destroy the data
structure when writing to the memory, as a result
of large numbers of defective sectors due to age.
In such cases there may be a complete loss of
data. Skymaster therefore recommends that a
back up copy of the memory content is made, so
that your data is not lost in case of data losses in
the USB memory.
