6 UPGRADING FIRMWARE
The CDP (and DVI) will be shipped with the most current version of firmware. Periodically, SKYTRAC Systems
will supply a new version of firmware that will add functionality to the CDP. These files will be available on the
SKYTRAC website (www.skytrac.ca) to download and install. See the DVI user guide (DOC0499) for updating
firmware on the DVI-300.
6.1 REQUIREMENTS
You will need the following to perform a firmware upload:
Windows PC with an available serial port.
A 9-wire Serial Cable to connect the PC to the CDP-300 programming port.
Alternatively, a USB to serial cable may be used in place of a 9-wire serial cable.
The latest CDP firmware upload package
Note: This procedure has been tested on a PC running Windows 7. Other versions of Windows may be
compatible, but have not been tested. SKYTRAC recommends using Windows 7.
6.2 FIRMWARE UPGRADE SETUP
1. Remove the CDP-300 from the aircraft mount by turning the 4 DZUS fasteners counter clockwise ¼ turn.
2. Pull the CDP-300 out. Do not disconnect the DB15 connector from the wiring harness.
3. Remove the protective covers (if installed) from the DB9 programming connector on the back of the CDP-
300.
4. Extract the CDP-xxx-xx_xx_xx.zip file to a directory on the Windows PC.
6.3 FIRMWARE UPGRADE INSTRUCTIONS
1. Connect the Serial Cable to a serial port on the Windows PC. Connect the other end of the Serial Cable to
the DB-9 programming port connector on the back of the CDP.
2. Double-click the CDP-xxx-xx.xx.xx-uploader.bat file that was extracted to the directory on the Windows PC.
This will begin the upload process and a DOS Window will appear as shown below:
