Table 14.126. 0x00E4
Reg Address Bit Field Type Setting Name Description
0x00E4 0 S NVM_READ_BANK When set, this bit will read the NVM down into the vola-
tile memory.
Table 14.127. 0x00F6
Reg Address Bit Field Type Setting Name Description
0x00F6 0 R REG_0XF7_INTR Set by CBPro
0x00F6 1 R REG_0XF8_INTR Set by CBPro
0x00F6 2 R REG_0XF9_INTR Set by CBPro
Table 14.128. 0x00F7
Reg Address Bit Field Type Setting Name Description
0x00F7 0 R SYSINCAL_INTR Set by CBPro
0x00F7 1 R LOSXAXB_INTR Set by CBPro
0x00F7 2 R LOSREF_INTR Set by CBPro
0x00F7 3 R LOL_INTR Set by CBPro
0x00F7 4 R LOSVCO_INTR Set by CBPro
0x00F7 5 R SMBUS_TIME_OUT_INTR Set by CBPro
Table 14.129. 0x00F8
Reg Address Bit Field Type Setting Name Description
0x00F8 3:0 R LOS_INTR Set by CBPro
Table 14.130. 0x00FE Device Ready
Reg Address Bit Field Type Setting Name Description
0x00FE 7:0 R DEVICE_READY Ready Only byte to indicate device is ready. When read
data is 0x0F one can safely read/write registers. This
register is repeated on every page therefore a page
write is not ever required to read the DEVICE_READY
