Register Value (Decimal) Divider Value
0 1 (bypass)
1 2
2 4
3 8
4 16
5 32
6 64
7 128
8 256
9 512
10 1024
11 2048
12 4096
13 8192
14 16384
15 32768
16 65536
Table 14.123. 0x009E
Reg Address Bit Field Type Setting Name Description
0x009E 7:4 R/W LOL_SET_THR Configures the loss of lock set thresholds
Table 14.124. 0x00E2 Active NVM Bank
Reg Address Bit Field Type Setting Name Description
0x00E2 7:0 R ACTIVE_NVM_BANK 0x03 when no NVM burn by customer
0x0F when 1 NVM bank has been burned by custom-
er
0x3F when 2 NVM banks have been burned by cus-
tomer
When ACTIVE_NVM_BANK = 0x3F, the last bank
has already been burned. See 3.2 NVM Programming
for a detailed description of how to program the NVM.
Table 14.125. 0x00E3
Reg Address Bit Field Type Setting Name Description
0x00E3 7:0 R/W NVM_WRITE Write 0xC7 to initiate an NVM bank burn.
