Register Address Description (Same as) Address
0x0119 OUT1_AMPL, OUT1_CM 0x0114
0x011A OUT1_MUX_SEL, OUT1_VDD_SEL_EN, OUT1_VDD_SEL, OUT1_INV 0x0115
0x0126 OUT2_PDN, OUT2_OE, OUT2_RDIV_FORCE2 0x0112
0x0127 OUT2_FORMAT, _SYNC_EN, DIS_STATE, _CMOS_DRV 0x0113
0x0128 OUT2_AMPL, OUT2_CM 0x0114
0x0129 OUT2_MUX_SEL, OUT2_VDD_SEL_EN, OUT2_VDD_SEL, OUT2_INV 0x0115
0x012B OUT3_PDN, OUT3_OE, OUT3_RDIV_FORCE2 0x0112
0x012C OUT3_FORMAT, _SYNC_EN, DIS_STATE, _CMOS_DRV 0x0113
0x012D OUT3_AMPL, OUT3_CM 0x0114
0x012E OUT3_MUX_SEL, OUT3_VDD_SEL_EN, OUT3_VDD_SEL, OUT3_INV 0x0115
Table 14.137. 0x013F-0x0140
Reg Address Bit Field Type Setting Name Description
0x013F 7:0 R/W OUTX_AL-
WAYS_ON
This setting is managed by CBPro during zero delay
mode.
0x0140 11:8 R/W OUTX_AL-
WAYS_ON
Table 14.138. 0x0141
Reg Address Bit Field Type Setting Name Description
0x0141 5 R/W OUT_DIS_LOL_MS
K
Set by CBPro
0x0141 7 R/W OUT_DIS_MSK_LO
S_PFD
Set by CBPro
Table 14.139. 0x0145 Power Down All Outputs
Reg Address Bit Field Type Setting Name Description
0x0145 0 R/W OUT_PDN_ALL 0: No effect
1: All drivers powered down
Si5341, Si5340 Rev D Family Reference Manual • Register Map
