SLAYER STEAM EP USER MANUAL V1.1 | SEPTEMBER 11, 2018 23
3. Press the button again to accept a null password
4. Scroll to select Manager, use any combination of numbers and letters
followed by a space < > indicating the end of the password
5. Scroll to select Advanced, use any combination of numbers and letters
followed by a space < > indicating the end of the password
6. Long press and hold the menu button to save and exit back to the
Home screen
To disable the passwords the user is permitting access to change multiple
details within the machines setup with the exception of a few outliers.
Disable Passwords: Manager & Advanced Menu’s
1. Scroll to Advanced menu
2. Scroll counter clockwise to Password
3. Enter the menu and select Manager or Advanced
4. Scroll to the first slot for character to the numerical value 0, one more
click counterclockwise to a blank space or <null> value between the
brackets Ex; < >
5. Press to select and the password for that menu is now set to null
NOTE: Setting the Advanced password to <null> (o) disables
programming a password for the Manager menu.
PROTIP: Hold the button for 2 seconds to go back to the last
screen, and 5 seconds to return to the home menu.
The Home Display Menu is rich with real time details on multiple
functions within the machine.
• Heating element activity, represented by a colon (“:”). When a brew
tank is being heated, the colon will flash near the brew temperature
reading on the corresponding screen.
• Steam tank fill status, represented by an upward-facing arrow. When
the steam tank is being filled, the arrow will appear next to the steam
tank pressure reading.
• Brew temperature (“Temp”) reading, displayed in tenth-degree
(0.1-degree) increments in Fahrenheit or Celsius.
• Brew time (“Time”) for the previous extraction, displayed in tenth-
second (0.1-second) increments. At the beginning of each extraction,
the timer will automatically reset and begin counting up from zero (0).
At the end of each extraction, the timer will automatically stop and
will remain visible until the next extraction begins. Button activations
under 2 seconds will not reset the shot time, and under 5 second will
not count as a shot in the shot counter. This is to allow the barista an
opportunity to flush or purge the group cap after an extraction and still
see the value of your previous extraction.
• Steam tank pressure (“Stm”) reading, displayed in 0.1-bar increments.
MENU OPTIONS
The first level of navigation is the Default Display menu which houses
several quick informational updates for your referencing.
1. Group Extraction Times
2. Temperatures
3. Shot Counter Stats Per Group Head
4. Passwords
5. Group Cleaning-Full Clean
6. Group Cleaning-Quick Clean
7. Switch O
Default Display: Group Extraction Times
SCREEN EXAMPLE:
Gp1: Gp2: Gp3: Stm:
25.2 24.0 25.4 1.5↑
PROTIP: Scrolling counter clockwise intentionally showcases the Group
Cleaning - Quick and Full to encourage cleaning whenever possible.
The last espresso brew shot time is noted below it’s perspective group.
Steam tank pressure is displayed on the far right of the screen. The timer
does not reset unless it runs for longer than two seconds. This allows the
barista to purge the group of residue and not lose sight of the previous
shot time.
Brew Group Temperatures
SCREEN EXAMPLE:
Gp1: Gp2: Gp3: TEMP
201.0 201.0 201.0
Scrolling clockwise (or counterclockwise) through the menu will enable
multiple screens. The current brew group temperatures are shown here.
(One fewer group will be displayed for a two-group model).
Shots Dispensed Per Group
A shot count is recorded every time a button remains in use longer than
five seconds. To view the number of times a shot has been extracted, use
the following steps.
