WIRE MAP: 3-GROUP MACHINES
GROUP 1 connection position wire color
SHORT BREW SW. CN14 2 YELLOW
1 BLACK/MAROON
LONF BREW SW. CN8 10 WHITE
RTD CN10 1 BLACK/WHITE
2 RED
SHORT LED CN19 2 BLACK/ORANGE
LONG LED CN32 2 WHITE/ORANGE
FLOW METER CN2 6 YELLOW/GREEN
BREW SOLENOID CN48 7 BLUE/WHITE
BREW HEATER SSR CN18 2 GRAY
GROUP 2 connection position wire color
SHORT BREW SW. CN17 2 YELLOW
1 BLACK/WHITE
LONF BREW SW. CN8 16 ORANGE
RTD CN13 1 BLACK/BROWN
2 RED
SHORT LED CN21 2 BLACK/BLUE
LONG LED CN34 2 WHITE/BLUE
FLOW METER CN2 7 YELLOW/ORANGE
BREW SOLENOID CN48 6 BLUE/BROWN
BREW HEATER SSR CN20 2 GRAY/YELLOW
GROUP 2 connection position wire color
SHORT BREW SW. CN25 2 YELLOW
1 BLACK/WHITE
LONF BREW SW. CN8 14 ORANGE
RTD CN16 1 BLACK/BROWN
2 RED
SHORT LED CN27 2 BLACK/BLUE
LONG LED CN38 2 WHITE/BLUE
FLOW METER CN2 8 YELLOW/ORANGE
BREW SOLENOID CN48 5 BLUE/BROWN
BREW HEATER SSR CN26 2 GRAY/YELLOW
connection position wire color
GROUND CN2 1 GREEN
FLOW MTR GND CN2 2 BLACK
FLOW MTR +10Vdc CN2 3 RED
HOT WATER SW. CN11 2 VIOLET/BLACK
STEAM SW. LEFT CN8 6 GREEN
STEAM SW. RIGHT CN8 2 GRAY
STEAM SOL.-LEFT MOD2 2 RED/WHITE
STEAM SOL. - RIGHT MOD1 2 ORANGE
LEVEL PROBE CN2 4 GRAY
AUTOFILL SOL. CN48 3 BROWN/WHITE
HOT WATER SOL. CN48 2 BROWN/YELLOW
STEAM HEATER CN28 2 BLACK/ORANGE
24vDC + CN1 1 RED
- CN1 3 BLACK
PUMP 115/240Vac (L1) CN49 1 WHITE
PUMP (L2 OR N) CN49 3 YELLOW
