SMAR TP301 - Page 23

Local Adjustment Programming
3.3
S
Z
Ação
Rotação
Pos
Unit
Act
LoPos
UpPos
Damp
inc dec
execute
inc
Pprc
mA
Eu
F
Actr
Actd
execute
C
o
execute
execute
dec
Z
Z
Z
S
S
S
Z Z Z
Z
Z
Z Z Z
Z
SS
Z
SS
S
S
S
S
S
S
S
S
S
S
Z
S
Z
Action
Rotation
S
Figure 3.3 – Local Adjustment Configuration Tree
Description of the Parameters of the Local Adjustment Configuration Tree
POS – Position in Percentage
UNIT
Engineering Unit or Percentage.
Pprc
Position in Percentage.
mA (Milliampere)
Current.
Eu (End User's choice)
Position.
ºC (Degrees Celsius)
Temperature.
F (Degrees Fahrenheit)
Temperature.
ACT
Action.
Actr
Reverse action.
Actd
Direct action.
LOPOS (0% Position)
TRIM of inferior position.
UPPOS (100% Position)
TRIM of Superior Position.
