TP301 – Operation, Maintenance and Instructions Manual
4.4
Figure 4.2 – Four Possible Positions for Indicator
Anchor the main board (5) in the housing (8) with their screws (3). After tightening the protective cover
(1), mounting procedure is complete. The transmitter is ready to be energized and tested.
Interchangeability
Main board can be replaced by a similar new one keeping the operational features unchanged. The
transducer EEPROM has all the information related to the TRIM and factory default configuration.
Accessories
Configurator in platform PalmOS, included interface, USB cable, initialization and installation software.
