SMAR TP301 - Spare Parts List

TP301 – Operation, Maintenance and Instructions Manual
4.6
Spare Parts List
SPARE PARTS LIST
DESCRIPTION OF PARTS
POSITION
CODE
CATEGORY
(NOTE 1)
COVER WITH WINDOW
. Aluminum
1
204-0103
. 316 SS
1
204-0106
COVER O-RING (NOTE 3)
. Buna-N
2
204-0122
B
ALUMINUM HOUSING MAIN BOARD SCREW
. Units with indicator
3
304-0118
. Units without indicator
3
304-0117
STAINLESS STEEL HOUSING MAIN BOARD SCREW
. Units with indicator
3
204-0118
. Units without indicator
3
204-0117
DIGITAL INDICATOR
4
214-0108
MAIN ELECTRONIC CIRCUIT BOARD
5
400-0098
A
HOUSING LOCKING SCREW
. M4 Screw
6
204-0121
. M6 Without Head Screw
6
400-1121
COVER LOCKING SCREW
7
204-0120
HOUSING (NOTE 2)
8
(NOTE 5)
LOCAL ADJUSTMENT PROTECTION CAP
9
204-0114
IDENTIFICATION PLATE SCREW
10
204-0116
TERMINAL BLOCK ISOLATOR
11
400-0058
TERMINAL BLOCK HOLDING BOLT
. Cover Aluminum
12
304-0119
. Cover 316 SS
12
204-0119
COVER WITHOUT WINDOW
. Aluminum
13
204-0102
. 316 SS
13
204-0105
EXTERNAL GROUND BOLT
14
204-0124
SIX-SIDED INTERNAL PLUG
. 1/2" NPT Bichromatized
Carbon SteeL BR-EX D
15
400-0808
. 1/2" NPT 304 SST BR-EX D
15
400-0809
SIX-SIDED INTERNAL PLUG
. 1/2" NPT Bichromatized
Carbon SteeL
15
400-0583-11
. 1/2" NPT 304 SST
15
400-0583-12
SIX-SIDED EXTERNAL PLUG
. M20 X 1.5 316 SST
15
400-0810
. PG13.5 316 SST
15
400-0811
RETAINING BUSHING
. 3/4" NPT 316 SST
15
400-0812
CONNECTION COVER SCREW
16
400-0883
CONNECTION COVER SET
. Aluminum
16, 17, 18,
19
400-0884
. 316 SS
16, 17, 18,
19
400-0885
O-RING, Neck (NOTE 3)
. Buna-N
17
204-0113
B
CONNECTION COVER
. Aluminum
18
400-0074
. 316 SS
18
400-0391
ANALOG BOARD
19
400-0637
UNION BLOCK O-RING
20
400-0085
B
UNION BLOCK
. Aluminum
21
400-0386
. 316 SS
21
400-0387
POSITION SENSOR COVER SET
. Aluminum
22, 23, 24
400-0656
. 316 SS
22, 23, 24
400-0657
POSITION SENSOR BRACKET + POSITION SENSOR SENSOR +
FLAT CABLE
22
400-0090
POSITION SENSOR COVER
. Aluminum
23
400-0089
. 316 SS
23
400-0396
POSITION SENSOR COVER BOLT
24
400-0092
REMOTE POSITION SENSOR COVER SET(NOTE 4)
. Aluminum
25
400-0853
. 316 SS
25
400-0854
