SMAR TP301 - Page 37

Maintenance Procedures
4.7
SPARE PARTS LIST
DESCRIPTION OF PARTS
POSITION
CODE
CATEGORY
(NOTE 1)
CABLE SET + CONNECTOR
. 5 M
26
400-0857
. 10 M
26
400-0858
. 15 M
26
400-0859
. 20 M
26
400-0860
REMOTE EXTENSION SET
. Aluminum
27
400-0855
. 316 SS
27
400-0856
TRANSDUCER SET
. Aluminum
16 a 24
400-0038
. 316 SS
16 a 24
400-0400
MOUNTING BRACKET,"L" + CLAMP "U" TO PIPE 2"
. Carbon Steel
-
400-0339
. 316 SS
-
400-0340
MAGNETS
. Linear up to 50 mm
-
400-0035
. Linear up to 100 mm
-
400-0036
. Linear up to 30 mm
400-0748
. Rotary
-
400-0037
NOTA
Note 1: For category A it is recommended to keep in stock 25 parts installed for each set and 50 for category B.
Nota 2: Includes terminal block isolator, bolts (cover locking, ground and terminal block isolator) and identification plate without certification.
Note 3: O-rings are packaged with 12 units.
Nota 4: Includes cover, position sensor flat cable, and extension cable connector.
Nota 5: To specify the housing, use HOUSING ORDER CODE table.
HOUSING ORDER CODE
400-1314
HOUSING
COD.
Product
5
TP301
COD.
Communications Protocol
H
HART & 4-20 mA
COD.
Electrical Connection
0
½ NPT
A
M20 X 1.5
B
PG13.5
COD.
Housing Material
H0
Aluminum Housing (IP/Type)
H1
316 SST Housing (IP/Type)
H2
Aluminum for saline atmosphere (IPW/TYPE X)
H4
Copper Free Aluminium (IPW/TYPEX)
COD.
Painting
P0
Gray Munsell N 6.5 Polyester
P3
Black Polyester
P8
Without Painting
P9
Safety Blue Epoxy – Electrostatic Painting
COD.
Manufacturing Standard
S0
Smar
400-1314
5
H
*
*
*
*
TYPICAL MODEL NUMBER
* Select item.
