Chapter 2 Using basic features
docs.smarttech.com/kb/171875 18
Using the convenience panel
The convenience panel contains buttons for turning the display on and off, controlling the volume,
freezing and unfreezing the screen, and showing and hiding a screen shade. It also includes connectors
for USB peripherals and a computer or other input.
No. Name Procedure
1 Power
l
Press to wake the display or put it back into an energy saving
mode (see
Waking up the display and putting it back into energy
saving mode
on page16).
l
Press and hold for five seconds to turn off the display.
l
Press and hold for 10 seconds to restart the display.
Note
Restarting the display does not change the display’s settings or
delete saved files.
2 Volume increase
Press to increase the volume (see
Adjusting the volume
on
page26).
3 Volume decrease
Press to decrease the volume (see
Adjusting the volume
on
page26).
4
Freeze
Press to freeze and unfreeze the screen (see page30).
5
Microphone mute
Press to mute or unmute the microphone (see
Using the
microphone array
on page26).
6 USB Type A
connector
Connect USB drives and other devices you want to use with a
connected computer (see
Connecting USB drives, peripherals, and
other devices
on page37).
7 HDMI 3 input
Connect the HDMIvideo output of a computer or other input
source to use with the display (see page34).
8 USB Type-C
connector
Connect a computer or mobile device with a single connection for
touch, video, and audio. Or connect any USB Type-C peripheral
(such as a USBdrive, a keyboard, a mouse, and so on) to use with
the display (see page34).
The Power button’s color indicates the display’s status:
