smartmeter S10 73
28 Technical specifications
28.1 LNB/Tuner input
F-type connector IEC 169-24
Frequency range 950 MHz ~ 2150 MHz
Input level -65 dBm bis -25 dBm
LNB power supply 13/18 V, max. 700 mA
LNB control signal 22 kHz
DiSEqC control yes
28.2 Demodulator
Front-end-modul QPSK
Symbol rate 2 Mbps bis 45 Mbps
28.3 System resource
CPU 216MHz
SDRAM 1PC 16M X16bit/16Mbyte DDR
FLASH 1PC 16bit/4MByte
28.4 Video-Decoder
Data rate bis zu 15 Mbit/s
Video resolution 720×576(PAL) 720×480(NTSC)
Video format PAL, NTSC, SECAM
28.5 Connectors
Serial data interface USB
28.6 Power supply
Supply voltage 12,6 V
Li-oN battery 2700 mAh
Supply voltage (charger) 100 - 240 V ~, 50/60 Hz
28.7 Dimensions
Length x width x height 10,3 x 16,7x 4,5 cm
