Compass
smartmeter S10 65
17 Compass
 Press the MENU-button.
 Press the Exit. button.
 Press F1.
The internal digital compass is displayed.
 Lay the smartmeter S10 on a flat horizontal
surface.
 Turn the smartmeter S10 on the surface a few
times for calibration
The red side of the compass-needle shows to the north.
18 Capture Video
 Press the MENU-button.
 Press the Exit. button.
 Press F4.
The TV picture gets captured on the connected USB-storage device.
 Press EXIT to stop the recording.
Recorded broadcasts can be played via the USB-Menu.
