APC615 Pump Unit Controller User Manual
APC615 Pump Unit Controller Version 1.0 2017-10-20 Page 35 of 54
7.4 SELECTION OF SENSORS
Table 12 – Sensors Selection
No.
Type
Description
Remark
1
Temperature Sensor
0 Not used
1 Custom Res Curve
2 Custom 4-20mA curve
3 Custom Volt Curve
4 VDO
5 CURTIS
6 VOLVO-EC
7 DATCON
8 SGX
9 SGD
10 SGH
11 PT100
12 Voltage Type (0.5V-4.5V)
13-15 Reserved
Defined resistance’s range is
(0~1)KΩ, default is SGD sensor.
2
Fuel Level Sensor
0 Not used
1 Custom Res Curve
2 Custom 4-20mA curve
3 Custom Volt Curve
4 SGD
5 SGH
6 Voltage Type (0.5V-4.5V)
7-15 Reserved
Defined resistance’s range is
(0~1)KΩ, default is SGD sensor.
3
Pressure Sensor
0 Not used
1 Custom Res Curve
2 Custom 4-20mA curve
3 Custom Volt Curve
4 VDO 10bar
5 CURTIS
6 VOLVO-EC
7 DATCON 10bar
8 SGX
9 SGD
10 SGH
11 Voltage Type (0.5V-4.5V)
12~15 Reserved
Defined resistance’s range is
(0~1)KΩ, default is SGD sensor.
4
Flow Sensor
0 Not used
1 Custom Res Curve
2 Custom 4-20mA curve
3 Custom Volt Curve
4-15 Reserved
