APC615 Pump Unit Controller User Manual
APC615 Pump Unit Controller Version 1.0 2017-10-20 Page 50 of 54
Engine type: John Deere
13.11 MTU MDEC
Suitable for MTU engines, 2000 series, 4000series
Table 32 – X1 Connector
Terminals of controller
X1 connector
Remark
Fuel relay output
BE1
Starter relay output
BE9
-
E
Communication shielding wire (connect to ECU
terminal only)
CAN(H)
G
Using 120Ω impedance connecting wire.
CAN(L)
F
Using 120Ω impedance connecting wire.
Engine type: MTU-MDEC-303
13.12 MTU ADEC(SMART MODULE)
It is suitable for MTU engine with ADEC (ECU8) and SMART module.
Table 33 – ADEC (X1 Port)
Terminals of controller
ADEC (X1port)
Remark
Fuel relay output
X1 10
X1 Terminal 9 Connected to negative of battery
Starter relay output
X1 34
X1 Terminal 33 Connected to negative of battery
Table 34 SMART （X4 Port）
Terminals of controller
SMART (X4 port)
Remark
CAN(H)
X4 1
Using 120Ω impedance connecting wire.
CAN(L)
X4 2
Using 120Ω impedance connecting wire.
Engine type: MTU-ADEC
13.13 MTU ADEC(SAM MODULE)
It is suitable for MTU engine with ADEC (ECU7) and SAM module.
Table 35 ADEC (X1 Port)
Terminals of controller
ADEC (X1port)
Remark
Fuel relay output
X1 43
X1 Terminal 28 Connected to negative of battery
Starter relay output
X1 37
X1 Terminal 22 Connected to negative of battery
Table 36 SAM (X23 Port)
Terminals of controller
ADEC (X23port)
Remark
CAN(H)
X23 2
Using 120Ω impedance connecting wire.
CAN(L)
X23 1
Using 120Ω impedance connecting wire.
Engine type: Common J1939
