APC615 Pump Unit Controller User Manual
APC615 Pump Unit Controller Version 1.0 2017-10-20 Page 51 of 54
13.14 PERKINS
It is suitable for ADEM3/ ADEM4 engine control module. Engine type is 2306, 2506, 1106, and 2806.
Table 37 - Connector
Terminals of controller
Connector
Remark
Fuel relay output
1,10,15,33,34
Starter relay output
-
Connect to starter coil directly
CAN(H)
31
Using 120Ω impedance connecting wire.
CAN(L)
32
Using 120Ω impedance connecting wire.
Engine type: Perkins
13.15 SCANIA
It is suitable for S6 engine control module. Engine type is DC9, DC12, and DC16.
Terminals of controller
B1 connector
Remark
Fuel relay output
3
Starter relay output
-
Connect to starter coil directly
CAN(H)
9
Using 120Ω impedance connecting wire.
CAN(L)
10
Using 120Ω impedance connecting wire.
Engine type: Scania
13.16 VOLVO EDC3
Suitable engine control mode is TAD1240, TAD1241, and TAD1242.
Table 39 – “Stand alone” Connector
Terminals of controller
“Stand alone” connector
Remark
Fuel relay output
H
Starter relay output
E
Programmable output 1
P
ECU power supply
Programmable output 1 configured as “ECU
power”.
Table 40 – “Data bus” Connector
Terminals of controller
“Stand alone” connector
Remark
CAN(H)
1
Using 120Ω impedance connecting wire.
CAN(L)
2
Using 120Ω impedance connecting wire.
Engine type: Volvo
NOTE: When this type is selected, preheating time should be set to at least 3 seconds.
13.17 VOLVO EDC4
Suitable engine types are TD520, TAD520 (optional), TD720, TAD720 (optional), TAD721, TAD722, and
TAD732.
Terminals of controller
Connector
Remark
Fuel relay output
Expanded 30A relay, and
relay offers battery
voltage for terminal14.
Fuse is 16A
Start relay output
-
Connect to starter coil directly
1
Connected to negative of battery
CAN(H)
12
Using 120Ω impedance connecting wire.
