APC615 Pump Unit Controller User Manual
APC615 Pump Unit Controller Version 1.0 2017-10-20 Page 52 of 54
CAN(L)
13
Using 120Ω impedance connecting wire.
Engine type: VolvoEDC4
13.18 VOLVO-EMS2
Volvo Engine types are TAD734, TAD940, TAD941, TAD1640, TAD1641, and TAD1642.
Terminals of controller
Engine’s CAN port
Remark
Programmable output 1
6
ECU stop
Set programmable output 1 as “ECU stop”
Programmable output 2
5
ECU power
Set programmable output 2 as “ECU power”
3
Negative power
4
Positive power
CAN(H)
1(Hi)
Using 120Ω impedance connecting wire.
CAN(L)
2(Lo)
Using 120Ω impedance connecting wire.
Engine type: Volvo-EMS2, speed regulation can be implemented.
NOTE: When this type is selected, preheating time should be set to at least 3 seconds.
13.19 YUCHAI
It is suitable for BOSCH common rail pump engine.
Table 43 – Engine 42 Pins Port
Terminals of controller
Engine 42 pins port
Remark
Fuel relay output
1.40
Connect to engine ignition lock
Starter relay output
-
Connect to starter coil directly
CAN(H)
1.35
Using 120Ω impedance connecting wire.
CAN(L)
1.34
Using 120Ω impedance connecting wire.
Table 44 Engine 2 Pins Port
Battery
Engine 2 pins port
Remark
Battery Negative
Electrode
1
Wire diameter is 2.5mm
2
.
Battery Positive
Electrode
2
Wire diameter is 2.5mm
2
.
Engine type: BOSCH, speed regulation can be implemented.
13.20 WEICHAI
It is suitable for Weichai BOSCH common rail pump engine.
Table 45 - Engine Port
Terminals of controller
Engine port
Remark
Fuel relay output
1.40
Connect to engine ignition lock
Starter relay output
1.61
CAN(H)
1.35
Using 120Ω impedance connecting wire.
CAN(L)
1.34
Using 120Ω impedance connecting wire.
Engine type: GTSC1, speed regulation can be implemented.
NOTE: If there is any question about connection between controller and ECU communication, please feel
free to contact SmartGen’s service.
