13.7 CUMMINS QSZ13
Table 28 – Engine OEM Connector
Terminals of controller
OEM connector of engine
Remark
Fuel relay output
45
Starter relay output
-
Connect to starter coil directly
Programmable output 1
16&41
Setting to idle speed control, normally close
output. Making 16 connect to 41 during
high-speed running of controller via external
expansion relay.
Programmable output 2
19&41
Setting to pulse raise speed control, normally
open output. Making 19 connect with 41 for 0.1s
during high-speed warming of controller via
external expansion relay.
CAN(H)
1
Using 120Ω impedance connecting wire.
CAN(L)
21
Using 120Ω impedance connecting wire.
Engine type: QSZ13, speed regulation can be implemented.
13.8 DETROIT DIESEL DDEC III / IV
Table 29 - Engine CAN Port
Terminals of controller
CAN port of engine
Remark
Fuel relay output
Expand 30A relay,
battery voltage of ECU is
supplied by relay
Starter relay output
-
Connect to starter coil directly
CAN(H)
CAN(H)
Using 120Ω impedance connecting wire.
CAN(L)
CAN(L)
Using 120Ω impedance connecting wire.
Engine type: Common J1939
13.9 DEUTZ EMR2
Table 30 F Connector
Terminals of controller
F connector
Remark
Fuel relay output
Expand 30A relay,
battery voltage of 14 is
supplied by relay. Fuse is
16A.
Starter relay output
-
Connect to starter coil directly
-
1
Connect to battery negative pole
CAN(H)
12
Using 120Ω impedance connecting wire.
CAN(L)
13
Using 120Ω impedance connecting wire.
Engine type: VolvoEDC4
13.10 JOHN DEERE
Table 31 – 21 Pins Connector
Terminals of controller
21 pins connector
Remark
Fuel relay output
G, J
Starter relay output
D
CAN(H)
V
Using 120Ω impedance connecting wire.
CAN(L)
U
Using 120Ω impedance connecting wire.
