APC615 Pump Unit Controller User Manual
APC615 Pump Unit Controller Version 1.0 2017-10-20 Page 48 of 54
CAN(H)
A
Using 120Ω impedance connecting wire.
CAN(L)
B
Using 120Ω impedance connecting wire.
Engine type: Cummins ISB
13.4 CUMMINS QSX15-CM570
It is suitable for CM570 engine control module. Engine type is QSX15.
Table 23 – 50 Pins Connector
Terminals of controller
50 pins connector
Remark
Fuel relay output
38
Oil spout switch
Start relay output
-
Connect to starter coil directly
Table 24 – 9 Pins Connector
Terminals of controller
9 pins connector
Remark
-
SAE J1939 shield-E
CAN communication shielding wire (connect to
ECU terminal only)
CAN(H)
SAE J1939 signal-C
Using 120Ω impedance connecting wire.
CAN(L)
SAE J1939 return-D
Using 120Ω impedance connecting wire.
Engine type: Cummins QSX15-CM570
13.5 CUMMINS GCS-MODBUS
It is suitable for GCS engine control module. Use RS485-MODBUS to read information of engine. Engine
types are QSX15, QST30, QSK23 / 45/60/78 and so on.
Table 25 – D-SUB Connector 06
Terminals of controller
D-SUB connector 06
Remark
Fuel relay output
5&8
Outside expand relay, when fuel output, making
port 5 and 8 of the connector 06 be connected.
Start relay output
-
Connect to starter coil directly
Table 26 - D-SUB Connector 06
Terminals of controller
D-SUB connector 06
Remark
-
20
Communication shielding wire (connect to ECU
terminal only)
RS485+
21
Using 120Ω impedance connecting wire.
RS485-
18
Using 120Ω impedance connecting wire.
Engine type: Cummins QSK-MODBUS, Cummins QST-MODBUS, Cummins QSX-MODBUS
13.6 CUMMINS QSM11
Table 27 – Engine OEM Connector
Terminals of controller
OEM connector of engine
Remark
Fuel relay output
38
Start relay output
-
Connect with starter coil directly
CAN(H)
46
Using 120Ω impedance connecting wire.
CAN(L)
37
Using 120Ω impedance connecting wire.
Engine type: common J1939
