APC615 Pump Unit Controller User Manual
APC615 Pump Unit Controller Version 1.0 2017-10-20 Page 7 of 54
All output ports are relay-out;
Parameter setting: parameters can be modified and stored in internal FLASH memory and cannot
be lost even in case of power outage;
Multiple crank disconnect conditions (speed sensor, oil pressure) are optional;
Widely power supply range DC(8~35)V, suitable to different starting battery voltage environment;
Event log, real-time clock, scheduled start & stop pump unit (can be set as start pump unit once a
day/week/month);
Can control engine heater, cooler and fuel pump.
With maintenance function. Actions can be set when maintenance time due;
All parameters used digital adjustment, instead of conventional analog modulation with normal
potentiometer, more reliability and stability;
Waterproof security level IP65 due to rubber seal installed between the controller enclosure and
panel fascia;
Metal fixing clips enable perfect performance in high temperature environment;
Modular design, anti-flaming ABS plastic enclosure, pluggable connection terminals and
embedded installation way; compact structure with easy mounting.
3 SPECIFICATION
Table 3 – Technical Parameters
Items
Content
Working Voltage
DC8.0V to 35.0V, Continuous Power Supply.
Overall Consumption
<3W(Standby mode: ≤2W)
Speed Sensor Voltage
1.0 to 24V(effective value)
Speed Sensor Frequency
10000Hz (max)
Starter Relay Output
16A Connect to common port output
Fuel Relay Output
16A Connect to common port output
Programmable Relay Output 1
16A Connect to common port output
Programmable Relay Output 2
7A Connect to common port output
Programmable Relay Output 3
7A Connect to common port output
Programmable Relay Output 4
7A AC250V Volt free output
Programmable Relay Output 5
7A AC250V Volt free output
Programmable Relay Output 6
7A AC250V Volt free output
Analog Sensor
4 fixed sensors, 2 configurable sensors
Overall Dimensions
197 mm x 152 mm x 47 mm
Panel Cutout
186mm x 141mm
Working Condition
Temperature: (-25~+70)°C Humidity: (20~93)%RH
Storage Condition
Temperature: (-25~+70)°C
Protection Level
IP65 Gasket
Insulating Intensity
Apply AC2.2kV voltage between high voltage terminal and low

Smartgen APC615 Specifications

General

Brand	Smartgen
Model	APC615
Category	Controller
Language	English
