7.4 SELECTION OF SENSORS
Table 10 Sensor Selection
No.
Item
Description
Remark
1
Temperature
Sensor
0 Not used
1 User Configured (Resistor type
Curve)
2 VDO
3 SGH
4 SGD
5 CURTIS
6 DATCON
7 VOLVO-EC
8 SGX
9 Reserved
10 Reserved
11 Digital Closed
12 Digital Open
Users-defined
resistance type range is
0Ω-999.9Ω; default is
SGX sensor.
2
Pressure Sensor
0 Not used
1 User Configured (Resistor type
Curve)
2 VDO 10Bar
3 SGH
4 SGD
5 CURTIS
6 DATCON 10Bar
7 VOLVO-EC
8 SGX
9 Reserved
10 Reserved
11 Digital Closed
12 Digital Open
Users-defined
resistance type range is
0Ω-999.9Ω; default is
SGX sensor.
3
Oil Level Sensor
0 Not used
1 User Configured (Resistor type
Curve)
2 SGH
3 SGD
4 reserved
5 reserved
6 Digital Closed
7 Digital Open
Users-defined
resistance type range is
0Ω-999.9Ω; default is
SGD sensor.
