Table 24 Engine OEM Connector
Terminals of controller
engine OEM connector
Remark
Programmable output1
45
Start relay output
-
Connected to starter coil directly;
Programmable output 2
16&41
Set it as idling speed control, normal close
output; making 16 connected to 41 during
high-speed running via external expansion
relay;
Programmable output 3
19&41
Set it as pulse speed raise control, normal
open output; making 19 connected with 41
for 0.1s during high-speed warming via
external expansion relay;
CAN_SCR
-
CAN communication shielding line;
CAN(H)
1
Using impedance 120Ω connecting line;
CAN(L)
21
Using impedance 120Ω connecting line;
Engine type: Common J1939.
13.8 DETROIT DIESEL DDEC III / IV
Table 25 Engine CAN Connector
Terminals of controller
CAN port of engine
Remark
Programmable output1
Expand 30A relay;
supplying battery
voltage for ECU;
Set configurable output 1 as “Fuel Relay
Output”;
Start relay output
-
Connected to starter coil directly;
CAN_SCR
-
CAN communication shielding line;
CAN(H)
CAN(H)
Using impedance 120Ω connecting line;
CAN(L)
CAN(L)
Using impedance 120Ω connecting line;
Engine type: Common J1939.
13.9 DEUTZ EMR2
Table 26 F Connector
Terminals of controller
F connector
Remark
Programmable output1
Expand 30A relay,
providing battery voltage
for terminal 14; Fuse is
16A;
Set configurable output 1 as “Fuel Relay
Output”;
Start relay output
-
Connected to starter coil directly;
-
1
Connected to battery negative pole;
CAN_SCR
-
CAN communication shielding line;
CAN(H)
12
Using impedance 120Ω connecting line;
CAN(L)
13
Using impedance 120Ω connecting line;
Engine type: Volvo EDC4.
