HGM4100LT GENSET CONTROLLER USER MANUAL
HGM4100LT Genset Controller 2019-01-28 Version1.0 Page 7 of 48
3 SPECIFICATION OPERATION
Table 2 Technical Parameters
Items
Contents
Operating Voltage
DC8.0V to DC35.0V, Continuous Power Supply.
Power Consumption
<3W (standby ≤2W)
AC Gen Voltage Input:
3Phase 4Wire
3Phase 3Wire
Single Phase 2Wire
2Phase 3Wire
15V AC - 360 V AC (ph-N)
30V AC - 620 V AC (ph-ph)
15V AC - 360 V AC (ph-N)
15V AC - 360 V AC (ph-N)
AC Gen Frequency
50 Hz/60 Hz
Speed Sensor Voltage
1.0V to 24.0V (RMS)
Speed Sensor Frequency
10,000 Hz (max.)
Start Relay Output
5 A DC28V power supply output
Fuel Relay Output
5 A DC28V power supply output
Programmable Relay Output 1
1 A DC28V power supply output
Programmable Relay Output 2
1 A DC28V power supply output
Programmable Relay Output 3
1A DC28V power supply output
Programmable Relay Output 4
1A DC28V power supply output
Case Dimension
135mm x 110mm x 44mm
Panel Cutout
116mm x 90mm
CT Secondary Current
5A rated
Working Conditions
Temperature: (-25~+70)°C; Relative Humidity: (20~93)%RH
Storage Condition
Temperature: (-25~+70)°C
Protection Level
IP65: rubber seal installed between the controller enclosure and
panel screen.
Insulation Intensity
Apply AC2.2kV voltage between high voltage terminal and low
voltage terminal and the leakage current is not more than 3mA
within 1min.
Net Weight
0.32kg
