Smartgen HGM4100LT

HGM4100LT GENSET CONTROLLER USER MANUAL
HGM4100LT Genset Controller 2019-01-28 Version1.0 Page 46 of 48
13.16 VOLVO EDC3
It is suitable for engine type TAD1240, TAD1241, and TAD1242.
Table 35 “Stand alone” Connector
Terminals of controller
“Stand alone” connector
Remark
Programmable output1
H
Set configurable output 1 as “Fuel Relay
Output”;
Start relay output
E
Configurable output 2
P
ECU power;
Set configurable output 2 as "ECU power" ;
Table 36 “Data bus” Connector
Terminals of controller
“Data bus” connector
Remark
CAN_SCR
-
CAN communication shielding line;
CAN(H)
1
Using impedance 120Ω connecting line;
CAN(L)
2
Using impedance 120Ω connecting line;
Engine type: Volvo.
NOTE: When this engine type is selected, preheating time should be set at least 3 seconds.
13.17 VOLVO EDC4
It is suitable for engine types TD520, TAD520 (optional), TD720, TAD720 (optional), TAD721,
TAD722, and TAD732.
Table 37 Connector
Terminals of controller
Connector
Remark
Programmable output1
Expand 30A relay, and
relay offers battery
voltage to terminal 14.
Fuse is 16A;
Set configurable output 1 as “Fuel Relay
Output”;
Start relay output
-
Connected to starter coil directly;
1
Connected to negative of battery;
CAN GND
-
CAN communication shielding line;
CAN(H)
12
Using impedance 120Ω connecting line;
CAN(L)
13
Using impedance 120Ω connecting line;
Engine type: Volvo EDC4.
13.18 VOLVO-EMS2
It is suitable for Volvo Engine types: TAD734, TAD940, TAD941, TAD1640, TAD1641, and
TAD1642.
