HGM4100LT GENSET CONTROLLER USER MANUAL
HGM4100LT Genset Controller 2019-01-28 Version1.0 Page 45 of 48
13.13 MTU ADEC(SAM module)
It is suitable for MTU engine with ADEC (ECU7) and SAM module.
Table 31 ADEC (X1 port)
Terminals of controller
ADEC (X1port)
Remark
Programmable output1
X1 43
Set configurable output 1 as “Fuel Relay
Output”;
X1 Terminal 28 is connected to battery
negative;
Start relay output
X1 37
X1 Terminal 22 is connected to battery
negative;
Table 32 SAM (X23 port)
Terminals of controller
SAM (X23 port)
Remark
CAN_SCR
X23 3
CAN communication shielding line;
CAN(H)
X23 2
Using impedance 120Ω connecting line;
CAN(L)
X23 1
Using impedance 120Ω connecting line;
Engine type: Common J1939.
13.14 PERKINS
It is suitable for ADEM3/ ADEM4 engine control mode. Engine type is 2306, 2506, 1106, and 2806.
Table 33 Connector
Terminals of controller
Connector
Remark
Programmable output1
1,10,15,33,34
Set configurable output 1 as “Fuel Relay
Output”;
Start relay output
-
Connected to starter coil directly;
CAN_SCR
-
CAN communication shielding line;
CAN(H)
31
Using impedance 120Ω connecting line;
CAN(L)
32
Using impedance 120Ω connecting line;
Engine type: Perkins.
13.15 SCANIA
It is suitable for S6 engine control mode. Engine type is DC9, DC12, and DC16.
Table 34 B1 Connector
Terminals of controller
B1 connector
Remark
Programmable output1
3
Set configurable output 1 as “Fuel Relay
Output”;
Start relay output
-
Connected to starter coil directly;
CAN_SCR
-
CAN communication shielding line;
CAN(H)
9
Using impedance 120Ω connecting line;
CAN(L)
10
Using impedance 120Ω connecting line;
Engine type: Scania.
