HGM4100LT GENSET CONTROLLER USER MANUAL
HGM4100LT Genset Controller 2019-01-28 Version1.0 Page 44 of 48
13.10 JOHN DEERE
Table 27 21 Pins Connector
Terminals of controller
21 pins connector
Remark
Programmable output1
G, J
Set configurable output 1 as “Fuel Relay
Output”;
Start relay output
D
CAN_SCR
-
CAN communication shielding line;
CAN(H)
V
Using impedance 120Ω connecting line;
CAN(L)
U
Using impedance 120Ω connecting line;
Engine type: John Deere.
13.11 MTU MDEC
It is suitable for MTU engines, 2000 series, 4000series.
Table 28 X1 Connector
Terminals of controller
X1 connector
Remark
Programmable output1
BE1
Set configurable output 1 as “Fuel Relay
Output”;
Start relay output
BE9
CAN GND
E
CAN communication shielding line
(connected to one terminal only);
CAN(H)
G
Using impedance 120Ω connecting line;
CAN(L)
F
Using impedance 120Ω connecting line;
Engine type: MTU-MDEC-303.
13.12 MTU ADEC(SMART module)
It is suitable for MTU engine with ADEC (ECU8) and SMART module.
Table 29 ADEC (X1 port)
Terminals of controller
ADEC (X1port)
Remark
Programmable output1
X1 10
Set configurable output 1 as “Fuel Relay
Output”;
X1 Terminal 9 is connected to battery
negative;
Start relay output
X1 34
X1 Terminal 33 is connected to battery
negative;
Table 30 SMART (X4 port)
Terminals of controller
SMART (X4 port)
Remark
CAN_SCR
X4 3
CAN communication shielding line;
CAN(H)
X4 1
Using impedance 120Ω connecting line;
CAN(L)
X4 2
Using impedance 120Ω connecting line;
Engine type: MTU-ADEC.
