HGM6100LT Series Genset Controller User Manual Page 22 of 50
No.
Items
Range
Default
Description
0, it is from end of ETS solenoid delay to
genset at rest.
19(14)
Switch Close Time
(0.0-10.0)s
5.0
Mains’ or generator’s switch closing pulse
width, when it is 0, output is continuous.
20(15)
Flywheel Teeth
(10.0-300.0)
118
Number of flywheel teeth, it can detect
disconnection conditions and engine speed.
21(16)
Gen Abnormal Delay
(0-20.0)s
10.0
Over or under voltage alarm delay.
22(17)
Gen Over Voltage
Shutdown
(30-60000)V
264
When genset voltage is over the point,
generator over voltage is active. When the
point is 60000V, generator over voltage is
disabled.
23(18)
Gen Under Voltage
Shutdown
(30-60000)V
196
When generator voltage is under the point,
generator under voltage is active. When the
point is 30V, generator under voltage is
disabled.
24(19)
Gen Under Speed
Shutdown
(0-6000)r/min
1200
When the engine speed is under the point for
10s, shutdown alarm signal is sent out.
25(20)
Gen Over Speed
Shutdown
(0-6000)r/min
1710
When the engine speed is over the point for
2s, shutdown alarm signal is sent.
26(21)
Gen Under Frequency
Shutdown
(0-75.0)Hz
45.0
When generator frequency is lower than the
point (not equal to 0) for 10s, shutdown
alarm signal is sent.
27(22)
Gen Over Frequency
Shutdown
(0-75.0)Hz
57.0
When generator’s frequency is over the point
and continues for 2s, generator over
frequency is active.
28(23)
High Temperature
Shutdown
(80-300)ºC
98
When external connected temperature
sensor value is over this point, it sends out
high temp. alarm. This value is only judged
for external connected temp. sensor after
safety on time is over. When the value is 300,
warning alarm won’t be sent. (only suited for
temperature sensor, except for high temp.
alarm signal inputted by programmable input
port.)
29(24)
Low Oil Pressure
Shutdown
(0-400)kPa
103
When external connected oil pressure sensor
value is under this point, low oil pressure
delay is started (judged after safety on time
is over). When the value is 0, warning alarm
won’t be sent. (only suited for oil pressure
sensor, except for low oil pressure alarm
signal inputted by programmable input port.)
30(25)
Low Fuel Level
(0-100)%
10
When fuel level sensor value under this point
