HGM6100LT Series Genset Controller User Manual Page 23 of 50
No.
Items
Range
Default
Description
Warning Value
and remains for 10s, genset sends out
warning alarm, only warn but not shutdown.
31(26)
Loss of Speed Signal
Delay
(0-20.0)s
5.0
When the delay setting as 0s, it only warn but
not shutdown.
32(27)
Charge Alternator
Fail Voltage
Difference
(0-30)V
6.0
During generator is running, when voltage
difference between B+ and D+(WL) of
charger is higher than this point and remains
for 5s, controller will initiate shutdown alarm.
33(28)
Battery Over Voltage
(12-40)V
33.0
When generator battery voltage is over the
point and remains for 20s, battery over
voltage signal is active. It only warn but not
shutdown.
34(29)
Battery Under
Voltage
(4-30)V
8.0
When generator battery voltage is under the
point and remains for 20s, battery under
voltage signal is active. It only warn but not
shutdown.
35(30)
CT Ratio
(5-6000)/5
500
External connected current transformer ratio.
36(31)
Full Load Current
(5-6000)A
500
Rated current of generator, used for
calculating over load current.
37(32)
Over Current PCT
(50-130)%
120
When load current is over the point, the over
current delay is initiated.
38(33)
Over Current Delay
(0-3600)s
30
It is definite time. When load current is over
the point and remains for preset time, over
current signal is sent. When the delay is 0,
only warn but not shutdown.
39(34)
Fuel Pump On
(0-100)%
25
When the fuel level is lower than the set
value for 2s, send a signal to open fuel
pump.
40(35)
Fuel Pump Off
(0-100)%
80
When the fuel level is higher than the set
value for 2s, send a signal to close fuel
pump.
41(36)
Aux. Output 1 Set
(0-26)
2
Factory default: Energized to stop. See table
8
42(37)
Aux. Output 2 Set
(0-26)
3
Factory default: Idle control. See table 8.
43(38)
Aux. Output 3 Set
(0-26)
5
Factory default: Gen close output. See table
8
44(39)
Aux. Output 4 Set
(0-26)
6
Factory default: Mains close output. See
table 8.
45(40)
Aux. Input 1 Set
(0-23)
1
Factory default: High temperature shutdown.
See table 9.
46(41)
Aux. Input 1 Active
(0-1)
0
Factory default: close.
47(42)
Aux. Input 1 Delay
(0-20.0)s
2.0
