Smartgen HGM6100LT SERIES User Manual

HGM6100LT Series Genset Controller User Manual Page 24 of 50
No.
Items
Range
Default
Description
48(43)
Aux. Input 2 Set
(0-23)
2
Factory default: Low oil pressure shutdown.
See table 9.
49(44)
Aux. Input 2 Active
(0-1)
0
Factory default: close.
50(45)
Aux. Input 2 Delay
(0-20.0)s
2.0
51(46)
Aux. Input 3 Set
(0-23)
10
Factory default: Remote start. See table 9.
52(47)
Aux. Input 3 Active
(0-1)
0
Factory default: close to activate.
53(48)
Aux. Input 3 Delay
(0-20.0)s
2.0
54(49)
Aux. Input 4 Set
(0-23)
11
Factory default: Low fuel level warn. See
table 9.
55(50)
Aux. Input 4 Active
(0-1)
0
Factory default: close.
56(51)
Aux. Input 4 Delay
(0-20.0)s
2.0
57(52)
Aux. Input 5 Set
(0-23)
12
Factory default: Low coolant level warn. See
table 9.
58(53)
Aux. Input 5 Active
(0-1)
0
Factory default: close.
59(54)
Aux. Input 5 Delay
(0-20.0)s
2.0
60(55)
Power On Mode
(0-2)
0
0: Stop Mode; 1: Manual Mode; 2: Auto Mode
61(56)
Module Address
(1-254)
1
The communication address of controller.
62(57)
Password
(0-9999)
0318
See NOTE 5.
63(58)
Crank Disconnect
Condition
(0-6)
2
Conditions of disconnecting starter
(generator frequency, magnetic pickup
sensor, oil pressure), Each condition can be
used alone and simultaneously to separating
the start motor and engine as soon as
possible.
64(59)
Engine Speed of
Crank Disconnect
(0-3000)r/min
360
When engine speed is over this point, starter
will disconnect.
65(60)
Frequency of Crank
Disconnect
(0.0-30.0)Hz
14.0
When generator frequency is over this point,
starter will disconnect.
66(61)
Oil Pressure of Crank
Disconnect
(0-400)kPa
200
When the oil pressure is over this point,
starter will disconnect.
67(62)
High Temp. Shut
Inhibit
(0-1)
0
Default: when temperature is too high, the
genset alarms and shuts down. See NOTE3.
68(63)
Low OP Shut Inhibit
(0-1)
0
Default: when oil pressure is too low, it
alarms and shuts down. See NOTE4.
69(64)
AC System
(0-3)
0
0: 3P4W 1: 2P3W
2: 1P2W 3: 3P3W
70(65)
Temp. Sensor Curve
Type
(0-14)
4
SGD. See table 10.
71(66)
Pressure Sensor
Curve Type
(0-14)
4
SGD. See table 10.
72(67)
Fuel Level Sensor
Curve Type
(0-7)
3
SGD. See table 10.
