HGM6100LT Series Genset Controller User Manual Page 28 of 50
No.
Items
Range
Default
Description
125
(120)
Input Port 5 Action
Type
(0-2)
1
0: Inactive
1: Warn
2: Shutdown Alarm
126
(121)
Input Port 1 Action
Range
(0-3)
1
0: Normal Running Start
1: Start
2: Always
3: Inactive
127
(122)
Input Port 2 Action
Range
(0-3)
1
0: Normal Running Start
1: Start
2: Always
3: Inactive
128
(123)
Input Port 3 Action
Range
(0-3)
1
0: Normal Running Start
1: Start
2: Always
3: Inactive
129
(124)
Input Port 4 Action
Range
(0-3)
1
0: Normal Running Start
1: Start
2: Always
3: Inactive
130
(125)
Input Port 5 Action
Range
(0-3)
1
0: Normal Running Start
1: Start
2: Always
3: Inactive
NOTE1: The value in first line of “Number” column is for HGM6120LT and the value in brackets is for HGM6110LT.
NOTE2: Cloud service related configuration needs to be set through PC software.
NOTE3: If select high temperature inhibit, or set programmable input as “High Temperature Inhibit” (this input is
active), when temperature is higher than pre-setting threshold, controller sends warning signal only and not shutdown.
NOTE4: If select low oil pressure inhibit, or set programmable input as “Low Oil Pressure Inhibit” (this input is active),
when low oil pressure is lower than pre-setting threshold, controller sends warning signal only and not shutdown.
NOTE5: If default password (0318) isn’t changed, it doesn’t need to input when configuring parameters via PC
software; if the password is changed for the first time via PC software, it need to input password in password window.
NOTE6: Between input correct password and LCD back light haven’t got dark, input parameter numbers can enter
parameter setting interface when enters “Password Input” again.
NOTE7: In teeth configuration interface, if being in teeth configuration status and frequency is larger than 20Hz,
press start key for auto calculating teeth numbers and press confirm key for changing teeth numbers.
