HGM6100LT Series Genset Controller User Manual Page 27 of 50
No.
Items
Range
Default
Description
(102)
Sampling
1: ECU
108
(103)
Speed Sampling
Selection
(0-1)
1
0: Controller
1: ECU
109
(104)
Temp. Sampling
Selection
(0-1)
1
0: Controller
1: ECU
110
(105)
OP Sampling
Selection
(0-1)
1
0: Controller
1: ECU
111
(106)
ECU Shutdown
Setting
(0-1)
1
0: Enabled
1: Disabled
112
(107)
Low Oil Level
Shutdown
(0-1)
0
0: Enabled
1: Disabled
113
(108)
Idle Speed
(0-6000)
1400
Unit：RPM
114
(109)
Rated Speed
(0-6000)
2250
Unit：RPM
115
(110)
ECU Address
(0-0xFF)
33
Set in hexadecimal display (0x21).
116
(111)
Over Current
Protection Action
(0-2)
1
0: Inactive
1: Warn
2: Shutdown Alarm
117
(112)
Short-circuit
Protection Setting
Enabled
(0-1)
1
1: Enabled
0: Disabled
118
(113)
Short-circuit
Protection Action
(0-2)
1
0: Inactive
1: Warn
2: Shutdown Alarm
119
(114)
Short-circuit
Protection Threshold
(0-1000)
600
Unit: Ampere (A)
120
(115)
Short-circuit
Protection Time
Ratio
(0-30)
10
121
(116)
Input Port 1 Action
Type
(0-2)
1
0: Inactive
1: Warn
2: Shutdown Alarm
122
(117)
Input Port 2 Action
Type
(0-2)
1
0: Inactive
1: Warn
2: Shutdown Alarm
123
(118)
Input Port 3 Action
Type
(0-2)
1
0: Inactive
1: Warn
2: Shutdown Alarm
124
(119)
Input Port 4 Action
Type
(0-2)
1
0: Inactive
1: Warn
2: Shutdown Alarm
