HRX-OM-W058
Chapter 5 Display and setting of various functions
HRS-R Series 5.8 Signal for completion of preparation (TEMP READY)
5-21
5. Select READY band width (upper/lower temperature range) from the table below with
[▲] key or [▼] key, and confirm by pressing “SEL”.
Table 5.8-3 List of set value
Set value
Explanation
Initial
(Default setting)
Setting and checking are not available when
READY mode setting is OFF.
Centigrade
to
Set READY band width (upper/lower
temperature range) for the circulating fluid
temperature
Temperature unit is Centigrade : Setting unit is
0.1
o
C
Temperature unit is Fahrenheit : Setting unit is
0.1
o
F
Fahrenheit
to
READY time Set and checking
6. Press the [SEL] key once.
The set screen of READY time is displayed on the digital display.
7. Select READY time from the table below with [▲] key or [▼] key, and confirm by
pressing “SEL”.
Table 5.8-4 List of set value
Set value
Explanation
Initial value
(Default setting)
Setting and checking are not available when
READY mode setting is OFF.
to
Sets ultimate time.
Set unit is 1 sec.
8. Press the [MENU] key once.
Return to the main screen (screen displaying the circulating fluid temperature).
PV
SV
PV
SV
