SMC Networks HRS018-A 20 R Series User Manual

HRX-OM-W058
Chapter 5 Display and setting of various functions
5.8 Signal for completion of preparation (TEMP READY) HRS-R Series
5-20
5.8.2 Signal for completion of preparation (TEMP READY) setting /
checking
The table below shows the explanation of and initial value of set items of
signal for completion of preparation (TEMP. READY)
Table 5.8-1 List of set Signal for completion of preparation (TEMP READY)
Display
Item
Contents
Initial value
(Default setting)
READY mode
Sets signal for completion of preparation
(TEMP READY)
OFF
READY band width
(upper/lower
temperature range）
Sets temperature of signal for completion of
preparation.
0.0
o
C
READY time
Sets time of signal for completion of
preparation.
10 sec
1. Press and hold the [MENU] key for approx. 2 sec.
Repeat pressing the key until the setting screen for key-lock [ ] appears on the
digital display.
READY mode Setting and checking
2. Press the [SEL] key 3 times.
The set screen of ready mode is displayed on the digital display.
3. Select ｢ON｣ from the table below with [▲] key or [▼] key, and confirm by pressing
“SEL”.
Table 5.8-2 List of set value
Set value
Explanation
Initial
(Default setting)
Signal for completion of preparation (TEMP
READY) function OFF
○
Signal for completion of preparation (TEMP
READY) function ON
READY band width setting and checking
4. Press the [SEL] key once.
The set screen of READY band width (upper/lower temperature range) is displayed on
the digital display.
PV
SV
PV
SV
PV
SV
PV
SV
PV
SV
［MENU］
Press and
hold
［MENU］
Press and
hold
