4 How to use
-55-
No.PS※※-OMW0009-A
■[F 1] Setting of OUT1
The setting of output OUT1 can be performed.
Please refer to page 46 for the relationship between the set items and operation.
<Operation>
Press the UP or SET button in function selection mode to display [F 1].
Press the SET button. Move on to output setting.
Output setting
In OUT1, items other than the distance detection cannot be selected.
Press the SET button. Move on to output mode setting.
Output mode setting
Press the UP or DOWN button to select the required output mode.
Press the SET button to set. Move on to reversed output setting.
Reversed output setting
Press the UP or DOWN button to select the reversed output.
Press the SET button to set. Move on to switch point (distance) setting.
