SYMBOLS
UNITS
S Seconds.
CY Cycles of the main AC supply line.
Hz Hertz (Frequency)
V Volts in a.c. (steady) or d.c. (flashing)
O Phase Angle Degrees.
Ω Ohms
VA Power in Volt amperes
A Amperes
The floating decimal point is automatically placed to accommodate the
reading to the working measurement range’s accuracy.
Timer control
The following buttons are used to control the PTE-100-C PRO’s timer opera-
tion and various start/stop logics:
Successive presses of this button change the start and stop modes
of the timer. The various options are represented by different
combinations of the START and STOP LEDs on the left side of the
button. Refer to the Timer Start and Stop Modes section below.
Use this button to toggle the displayed time between seconds and
cycles (of the power line’s frequency).
This button returns the timer to zero and re-enables the automatic
power shut off. Injection will not stop automatically upon relay
operation if the timer is not previously reset. Please refer to the
Operation section for a more in-depth description of this feature.
Timer start/stop modes
You can adapt yourself to different timing conditions by setting up the vari-
ous combinations of start and stop events for the PTE-100-C PRO’s timer.
The default combination –first and third LEDs- sets the timer to start when the
current or voltage output are connected and to stop when operation is de-
tected at the monitor’s dry or wet contact inputs. Use the MODE button to
toggle between the available combinations:
Reset
Display
Mode
