PTE-100-C PRO
37
6) From now on, as long as you don’t move the test load to a different
tap, you can toggle the
Preset function on and off to acti-
vate/suspend the theoretical current calculation in Display #2. To
do this, just switch to Func. mode, navigate to the
Preset function
and press the button. If two beeps are heard instead of
one, repeat above steps 3) and 4) to properly measure and store
the connected impedance value in memory and try again.
While Preset is active, compare the displayed current values at Display #2
before and after pressing to activate the output. This will help you
estimate the amount of error introduced by the nature of the load and the
measurement and calculation method. The
Preset function is provided as a
means to help you save some regulation time. Refer to Special Functions at
the DESCRIPTION section for details on the use of the
Preset and |Z|tap
functions.
CALIBRATING THE PTE-100-C PRO
One of the microprocessor-supported functions in the PTE-100-C PRO is
the calibration and adjustment process. You don’t need to open the unit or
use any tools to readjust it. Just install the supplied FAA-CAL program on a
Windows PC, connect it to the unit’s serial port and follow the instructions to
enter the readings from reference instruments into your PTE-100-C PRO.
Required equipment
To calibrate and adjust the readings of your PTE-100-C PRO you need the
following equipment:
 RS-232 communications cable (supplied)
 FAA-CAL calibration utility (supplied) installed on a Windows PC
 Reference measurement instruments
The process consists basically of 1) comparing the readings in the PTE-100-
C PRO’s display to those measured by the reference equipment, 2) entering
the reference value through the program if the one displayed on the PTE-
100-C PRO is out of tolerance, and 3) producing a calibration report.
ON
Enter/Print
