Web Configuration
Displaying Status Overview
You can easily identify the system by displaying the device name, location
and contact information.
Field Attributes
System Information
• System Name – Name assigned to the switch system.
• Number of Ports – Number of built-in ports.
• Hardware Version – Hardware version of the main board.
• Code Version – Version number of the code.
• Serial Number – The serial number of the switch.
Address Information
• Management VLAN – ID of the configured VLAN (this is set to 1 and
cannot be changed) all ports on the unit are members of VLAN 1. The
management station must always be attached to a port on VLAN 1.
• IP Address – Address of the VLAN to which the management station
Port Security Sets security policy for port. 49
ACL Sets up management access filter. 51
IGMP Snoop 52
Settings Sets up IGMP Snooping configuration 54
Status Shows IGMPSNOOP instances and port
states.
54
SNMP 55
Settings Sets up SNMP agent. 55
LOGOUT Quits to the Login page.
