-23-
No.PS##-OML0003-B
4, Press the button to finish the setting.
For models with 2 outputs, [P_2] or [n_2] will be displayed. Set as above.
The Pressure switch moves within a set pressure range (from P1L to P1H) during window comparator
mode. Set P1L (switch lower limit) and P1H (switch upper limit) with the setting procedure above.
(When reversed output is selected, [n1L] and [n1H] are displayed.)
Zero clear of indication
Indication is reset to zero when
and buttons are pressed simultaneously for 1 second.
For the first operation, perform zero clear without pressure supply.
