-34-
No.PS##-OML0003-B
■[F 6] Setting of fine adjustment of display value
This is the function to perform fine adjustment of the displayed pressure manually.
It is adjustable within the range
±5%R.D.
<Operation>
Press the
or button in function selection mode to display [F 6].
Press the button. Move on to setting of fine adjustment of display value.
Press the button to set
Press the button to set. Return to function selection mode.
Setting of [F 6] fine adjustment of display value completed
Setting of fine adjustment of display value
Press the
or
button to change the set
pressure.
If the
and buttons are displayed
simultaneously for 1 second or longer while [FSC]
is displayed, the adjusted value is initialized
