-57-
No.PS##-OML0003-B
Specification
■Specifications
Model No.
ZSE30A
(For vacuum)
ZSE30AF
(For compound)
ISE30A
(For positive pressure)
Rated pressure range 0.0 to -101.0 kPa -100.0 to 100.0 kPa -0.100 to 1.000 MPa
Set pressure range 10.0 to -105.0 kPa -105.0 to 105.0 kPa -0.105 to 1.050 MPa
Withstand pressure 500 kPa 500 kPa 1.5 MPa
Min. display unit 0.1 kPa 0.1 kPa 0.001 MPa
Applicable fluid Air, inert gases and incombustible gases
Power supply voltage 12 to 24 VDC ±10%, ripple (p-p) 10% or less (Protected against inverse connection)
Current consumption 40 mA or less
Switch output
NPN or PNP open collector output 1 output
NPN or PNP open collector output 2 outputs (selectable)
Max. load current 80 mA
Max. applied voltage 28 V (NPN output)
Residual voltage 1 V or less (at 80 mA load current)
Response time
2.5 ms or less
(Chattering-proof function working: 20, 100, 500, 1000 or 2000 ms selected)
Short circuit protection Provided
Repeatability ±0.2%F.S. ±1 digit
Hysteresis mode
Hys
teresis
Window comparator mode
0 to variable
∗
1
Output Voltage
(rated pressure range)
1 to 5 V ±2.5%F.S.
0.6 to 5 V
±2.5%F.S.
Linearity ±1%F.S.
Voltage
output
∗
2
Output impedance Approx. 1 kΩ
Output current
(rated pressure range)
4 to 20 mA ±2.5%F.S.
2.4 to 20 mA
±2.5%F.S.
Linearity ±1%F.S.
Analog
output
Current
output
∗
3
Load impedance
Max. load impedance: 300 Ω (at power supply voltage of 12 VDC)
600 Ω (at power supply voltage of 24 VDC)
Min. load impedance: 50 Ω
Display method 4 digits 7-segment display, Dual-color display (red/green)
Indicator accuracy ±2%F.S. ±1digit (at ambient temperature 25±3 °C)
Indication light Light when ON OUT1: Green OUT2: Red
Enclosure IP40
Ambient temperature range Operation: 0 to 50 °C, Storage: -10 to 60 °C (No condensation or freezing)
Ambient humidity range Operation, Storage: 35 to 85%RH (No condensation)
Withstand voltage 1000 VAC, 1 minute Between lead block and case
Environ
ment
Insulation resistance 50 MΩ or more at 500 VDC Between lead block and case
Temperature characteristic ±2%F.S. (25 °C reference)
Lead wire
Oil resistance vinyl cabtyre cable
3 cores φ3.5, 2 m
4 cores Sectional area of conductor: 0.15 mm
2
(AWG26)
Outside diameter of insulator: 1.0 mm
Standard CE, UL/CSA, RoHS
∗1: If the applied voltage fluctuates around the set value, the hysteresis more than the fluctuating width needs to be set. Otherwise,
chattering will occur.
∗2: If analog voltage output is selected, the analog current output cannot be selected at the same time.
∗3: If analog current output is selected, the analog voltage output cannot be selected at the same time.
