SMC Networks ZSE30A(F) User Manual

-58-
No.PS##-OML0003-B
○Piping specifications
Model No. 01 N01 C4H C6H N7H C4L C6L N7L
Port size
R1/8
M5×0.8
NPT1/8
M5×0.8
- - - - - -
One-touch fitting
straight type
- -
φ4 mm
φ5/32 inch
φ6 mm φ1/4 inch - - -
One-touch fitting
elbow type
- - - - -
φ4 mm
φ5/32 inch
φ6 mm φ1/4 inch
Pressure
sensing part
Silicone
Wetted
part
material
Piping port
C3602
(Electro less
nickel plating)
O-ring: HNBR
PBT, POM, SUS304, C3604 (Electro less nickel plating)
O-ring: NBR
With connector
attached lead wire
(3-core, 2 m)
81 g 70 g 71 g 73 g 75 g 73 g 75 g
With connector
attached lead wire
(4-core, 2 m)
85 g 74 g 75 g 77 g 79 g 77 g 79 g
Weight
Without connector
attached lead wire
43 g 32 g 33 g 35 g 37 g 35 g 37 g
○Analog output
Voltage output Current output
Range Rated pressure range A B C
For vacuum 0.0 to -101.0 kPa - 0 -101 kPa
For compound -100.0kPa to 100.0 kPa - -100 kPa 100 kPa
For positive pressure -0.100 to 1.000 MPa -0.1 MPa 0 1 MPa
