SMC Networks ZSE30A(F) - Performing Output Checks for OUT1 and OUT2

-42-
No.PS##-OML0003-B
Press the
button to set
after returning
to [A] (normal
output).
Return to
function
selection mode.
Press and
hold
button for
2 seconds or
longer.
Setting of [F98] check of output completed Measurement mode
∗: If button is pressed and held for 2 seconds or longer, the mode is returned to the measurement mode regardless of the
current mode.
OUT2 check of
output
Press the
or
button to
select OUT2
check of output.
