7. Maintenance and repairs
7.7 WIRING DIAGRAM
10
7
6
5
4
3
2
1
8
8
9
Cod.
ET010134
EE500026 EE300030 EE300033 EE800015
Description spare
TRANSFORMER
FUSE
RELAY RELAY
NET FILTER
Pos.
6 7 8 9
10
Cod.
EE500045
ET010169
EE100076 EE100075 EE100073 EE500063
EE500011
Description spare
FUSE
TRANSFORMER
RELAY SWITCH
ANTI NOISE MODULE
RELAY SWITCH
FUSE SOCKET
FUSE
Pos.
1 2 3 4 5
